Ship a true NFT Marketplace on Celo - Part 2

For our NFT marketplace to show all listings on the marketplace, we need to somehow keep track of the currently active listings. This is where The Graph comes in!

The Graph is an indexer and decentralized query protocol for the blockchain. Basically, it can track events being emitted in real time, and transform that data by running user-defined scripts, and make it available through a simple GraphQL API.

We also cover The Graph in the Junior Track of Fundamentals. Check that out if you want another example of it's usage

The main motivation for us right now to do this is a way to fetch a list of all active listings on the contract. Since in the contract itself, listings are stored within a 2D mapping, it is impossible to know what key-value pairs exist within the mapping since the possibilities are too large, and there is no way to just find values that exist within mappings and ignore the 'unset' values.

The Graph will allow us to use the events we emit from the smart contract to build up kind of a database of all listings, which we can create, read, update, and delete from. We can then just get a list of all listings by querying the database through it's GraphQL API.

Subgraph Development

The way to utilize The Graph's technology is to build your own "subgraph" - a project that defines your data transformation scripts, which contract and which network you want to track, which events you want to index, and how you want the GraphQL API to expose your data.

🧶 Installing Yarn

The Graph requires using yarn to install dependencies. yarn is an alternative package manager for Node.js, similar to npm.

If you don't have yarn installed on your computer, you can install it by running the following command:

npm install -g yarn

👨‍🔬 Setting Up

Let's create a new folder and set up a Graph project in there.

Open up a terminal, and install the Graph CLI on your computer globally

yarn global add @graphprotocol/graph-cli

Enter the celo-nft-marketplace directory from your terminal

cd celo-nft-marketplace

Initialize a new subgraph project by running the following command.

graph init

Select ethereum as the protocol when the CLI prompts you to choose
Select hosted-service for the Product
Enter your subgraph name that follows the format GITHUB_USERNAME/celo-nft-marketplace where GITHUB_USERNAME should be your Github username
Enter subgraph for the Directory to create the subgraph in
Select celo-alfajores for the network
Input the contract address of your NFT Marketplace contract as deployed in Part 1
Enter ./hardhat/artifacts/contracts/NFTMarketplace.sol/NFTMarketplace.json for the ABI path - this refers to the ABI generated by Hardhat when you compile it
Enter NFTMarketplace for the Contract Name
Wait for the CLI to set up your project

😎 Git Good

The Graph CLI also initializes a Git repo when it sets up the project. However, since we are creating the subgraph within the parent celo-nft-marketplace directory, which ideally should be the git repository, we will delete the git repo that has been initialized within the subgraph folder.

This is done so we don't end up having Git Submodules, i.e. a repo inside a repo, which can be annoying.

Run the following command in your terminal, from the subgraph directory:

# Linux / macOS
cd hardhat
rm -rf .git

# Windows
cd hardhat
rmdir /s /q .git

Also, let's create a .gitignore file, because for some reason the Graph CLI does not do that (even though it initializes a Git repo, lol). Without it, when you try pushing to Github you will end up pushing all your node_modules and auto-generated files as well, which is never good.

Create a file named .gitignore within the subgraph directory using VS Code, or your preferred code editor, and add the following lines to it:

build/
node_modules/
generated/

This will mark the three folders mentioned as ignored and they will not be pushed to Github when you attempt to do so.

🔑 Adding your Deploy Key

You need to set up a deployment key, so that the CLI knows which account to deploy the subgraph to. To do this, you first need to login to the website and retrieve your key.

Login to The Graph Hosted Service using your Github account
Open your dashboard
Copy the Access Token that's present on your dashboard

Now, in your terminal, run the following command while pointing to the subgraph directory

graph auth

Select hosted-service for the Product, and then enter your access token. If you see something like:

Deploy key set for https://api.thegraph.com/deploy/

then you're all set to go!

⛩ File Structure

At this point, you should have reached a file structure that looks like this.

subgraph/
├─ abis/
│  ├─ NFTMarketplace.json
├─ generated/
│  ├─ NFTMarketplace/
│  │  ├─ NFTMarketplace.ts
│  ├─ schema.ts
├─ node_modules/
├─ src/
│  ├─ nft-marketplace.ts
├─ package.json
├─ schema.graphql
├─ subgraph.yaml
├─ tsconfig.json
├─ yarn.lock

Note: Subgraph projects seem to be using Typescript by default. Actually, they use a tighter subset of Typescript called AssemblyScript. This is because the scripts we will write get compiled into WebAssembly (WASM) and run on The Graph's nodes. AssemblyScript is a stricter version of Typescript that can be compiled into WASM - whereas full-featured Javascript/Typescript cannot be. Other languages such as Rust, Golang, C, C++, etc can also be compiled into WASM.

There are three main files we will be touching in this project, and should take time to understand.

subgraph.yaml
schema.graphql
src/nft-marketplace.ts

🤨 The Manifest

subgraph.yaml is your manifest - it defines the contract to listen for events to, the specific events to listen to, defines the network on which this lives, and provides other metadata.

If we open that file, it should look something like this:

specVersion: 0.0.4
schema:
  file: ./schema.graphql
dataSources:
  - kind: ethereum
    name: NFTMarketplace
    network: celo-alfajores
    source:
      address: "0x627f152f97d431B844604B4421313CA979712006"
      abi: NFTMarketplace
    mapping:
      kind: ethereum/events
      apiVersion: 0.0.5
      language: wasm/assemblyscript
      entities:
        - ListingCancelled
        - ListingCreated
        - ListingPurchased
        - ListingUpdated
      abis:
        - name: NFTMarketplace
          file: ./abis/NFTMarketplace.json
      eventHandlers:
        - event: ListingCancelled(address,uint256,address)
          handler: handleListingCancelled
        - event: ListingCreated(address,uint256,uint256,address)
          handler: handleListingCreated
        - event: ListingPurchased(address,uint256,address,address)
          handler: handleListingPurchased
        - event: ListingUpdated(address,uint256,uint256,address)
          handler: handleListingUpdated
      file: ./src/nft-marketplace.ts

Few things to note here:

dataSources is the main block we want to focus on, and is literally used to define the data source for our indexer
source block defines the contract address and a reference to its ABI. Note that the ABI is only given a name, as the actual file path is referenced to later in the abis block
eventHandlers has the definitions of all the events our contract had, which the CLI was able to automatically generate from looking at the ABI. Each event also has a handler defined, which will be the function name within our script to handle data coming from that event.
file references /src/nft-marketplace.ts - this is where we will write our script.

For now, we will just make one small change to this manifest. Since The Graph works by scanning every block of the blockchain trying to find events which match your data sources, by default, it will start scanning from the genesis block of the blockchain.

A Genesis Block is the name given to the first block of a cryptocurrency. In this case, it's the block 0 of Celo.

However, that will take a lot of time, as there are millions of blocks which we know for sure don't have any events we are interested in, since our contract was only recently deployed.

Therefore, to speed it up, we can define a startBlock field to tell The Graph where to start scanning from. We will set this value to be the block in which our contract was deployed.

Search up your contract address on CeloScan, find the Contract Creation transaction, copy the block number of that transaction, and add the following line to your manifest:

specVersion: 0.0.4
schema:
  file: ./schema.graphql
dataSources:
  - kind: ethereum
    name: NFTMarketplace
    network: celo-alfajores
    source:
      address: "0x627f152f97d431B844604B4421313CA979712006"
      abi: NFTMarketplace
+     startBlock: 12832773
    mapping:
      kind: ethereum/events
      apiVersion: 0.0.5
      language: wasm/assemblyscript
      entities:
        - ListingCancelled
        - ListingCreated
        - ListingPurchased
        - ListingUpdated
      abis:
        - name: NFTMarketplace
          file: ./abis/NFTMarketplace.json
      eventHandlers:
        - event: ListingCancelled(address,uint256,address)
          handler: handleListingCancelled
        - event: ListingCreated(address,uint256,uint256,address)
          handler: handleListingCreated
        - event: ListingPurchased(address,uint256,address,address)
          handler: handleListingPurchased
        - event: ListingUpdated(address,uint256,uint256,address)
          handler: handleListingUpdated
      file: ./src/nft-marketplace.ts

🧱 The Schema

Now let's take a look at the schema.graphql file.

This file defines the entities, or the types, of data that make up the set of possible data you want to query on the service. If you have ever worked with traditional databases, like MongoDB or MySQL before, you can think of Entities as models or tables in the database, where each piece of data needs to conform to that type.

By default, it looks something like this

type ExampleEntity @entity {
  id: ID!
  count: BigInt!
  nftAddress: Bytes! # address
  tokenId: BigInt! # uint256
}

Now, let's think about the data we want to be storing and indexing. The whole point of doing this is being able to fetch all active listings at any given point, so we can display them on our dApp properly.

Even though we have four events - ListingCreated, ListingUpdated, ListingCancelled, and ListingPurchased - all four of them revolve around the concept of 'Listings'.

Therefore, we can just use a single data model/entity - ListingEntity - which uniquely identifies a certain listing. When a new listing is created, a new entity is created. Any updates made will update the existing entity. Cancelling will delete that entity. Purchases will mark that entity as purchased, to display appropriately.

If you're still confused, don't worry, once we start writing a script and seeing it in action it will make more sense. Also, always feel free to ask on the Discord for help!

For now, let's replace the contents of the file with the following

type ListingEntity @entity {
  id: ID!
  nftAddress: Bytes! # address
  tokenId: BigInt! # uint256
  price: BigInt! # uint256
  seller: Bytes! # address
  # The exclamation mark (!) resembles a *required* property
  # Lack of an exclamation mark resembles an optional property
  # Since the listing will not have a buyer until it is sold,
  # We mark the buyer as an optional property
  buyer: Bytes # address
}

👀 The Script

Great, we're now finally at the point where we can write our actual script.

One last quick thing before we do that though, run the following command in your terminal

graph codegen

What this does is, it converts our schema.graphql entity into Typescript (actually, AssemblyScript) types so we can do type-safe programming in our script. We will see how now!

Open up src/nft-marketplace.ts, and get rid of the sample code, we will understand what we're doing as we go. Replace it with the following:

import {
  ListingCancelled,
  ListingCreated,
  ListingPurchased,
  ListingUpdated,
} from "../generated/NFTMarketplace/NFTMarketplace";
import { store } from "@graphprotocol/graph-ts";
import { ListingEntity } from "../generated/schema";

export function handleListingCreated(event: ListingCreated): void {}

export function handleListingCancelled(event: ListingCancelled): void {}

export function handleListingPurchased(event: ListingPurchased): void {}

export function handleListingUpdated(event: ListingUpdated): void {}

See the files being imported from the generated folder? That's what graph codegen does. It converts our contract events and GraphQL entity definitions into Typescript types, so we can use them for type-safe programming in our script.

We have four functions to fill out - the handle for each of the events as defined in our manifest. Let's start with the first one, handleListingCreated. Insert the following code into the function.

export function handleListingCreated(event: ListingCreated): void {
  // Create a unique ID that refers to this listing
  // The NFT Contract Address + Token ID + Seller Address can be used to uniquely refer
  // to a specific listing
  const id =
    event.params.nftAddress.toHex() +
    "-" +
    event.params.tokenId.toString() +
    "-" +
    event.params.seller.toHex();

  // Create a new entity and assign it's ID
  let listing = new ListingEntity(id);

  // Set the properties of the listing, as defined in the schema,
  // based on the event
  listing.seller = event.params.seller;
  listing.nftAddress = event.params.nftAddress;
  listing.tokenId = event.params.tokenId;
  listing.price = event.params.price;

  // Save the listing to the nodes, so we can query it later
  listing.save();
}

Great, the comments in the code should explain what we're doing, but basically

We create a new entity
We assign values to the entity based on the event
We save the entity in the store

Now, let's do handleListingUpdated, and see how we modify already existing entities. Insert the following code into the function.

export function handleListingUpdated(event: ListingUpdated): void {
  // Recreate the ID that refers to the listing
  // Since the listing is being updated,
  // the datastore must already have an entity with this ID
  // from when the listing was first created
  const id =
    event.params.nftAddress.toHex() +
    "-" +
    event.params.tokenId.toString() +
    "-" +
    event.params.seller.toHex();

  // Attempt to load a pre-existing entity, instead of creating a new one
  let listing = ListingEntity.load(id);

  // If it exists
  if (listing) {
    // Update the price
    listing.price = event.params.newPrice;

    // Save the changes
    listing.save();
  }
}

Awesome! Now, let's do handleListingCancelled. We don't want to display canceled listings on the marketplace, so we can just delete the entity from the datastore entirely. Insert the following code into the function.

export function handleListingCancelled(event: ListingCancelled): void {
  // Recreate the ID that refers to the listing
  // Since the listing is being updated, the datastore must already have an entity with this ID
  // from when the listing was first created
  const id =
    event.params.nftAddress.toHex() +
    "-" +
    event.params.tokenId.toString() +
    "-" +
    event.params.seller.toHex();

  // Load the listing to see if it exists
  let listing = ListingEntity.load(id);

  // If it does
  if (listing) {
    // Remove it from the store
    store.remove("ListingEntity", id);
  }
}

One thing to note in this code is that there is no way to delete entities using the generated Typescript types directly. i.e. We cannot do something like listing.remove(). Instead, we have to use store.remove() where store is imported from The Graph's libraries. This function takes two parameters - a string which refers to the entity name, in our case ListingEntity, and the ID to delete.

Other than that, the code should be pretty straightforward. We just load an entity from the store, and if it exists, we delete it. So it will no longer show up when we query for listings later.

Lastly, let's do handleListingPurchased. In this case, we do not want to delete the listing, we just want to set the buyer property on it. Then, in the frontend, we can differentiate active listings from sold listings based on whether or not the buyer property is present, and then render them accordingly. Insert the following code into the function.

export function handleListingPurchased(event: ListingPurchased): void {
  // Recreate the ID that refers to the listing
  // Since the listing is being updated, the datastore must already have an entity with this ID
  // from when the listing was first created
  const id =
    event.params.nftAddress.toHex() +
    "-" +
    event.params.tokenId.toString() +
    "-" +
    event.params.seller.toHex();

  // Attempt to load a pre-existing entity, instead of creating a new one
  let listing = ListingEntity.load(id);

  // If it exists
  if (listing) {
    // Set the buyer
    listing.buyer = event.params.buyer;

    // Save the changes
    listing.save();
  }
}

Beautiful! We're done writing our script! Now, time to ship.

🚢 Ship It

The only thing left for us to do now is deploy our subgraph, and watch as the magic happens!

There is only one thing we need to do before that, which is we need to visit our Graph Dashboard, and create a new subgraph definition there.

Open the dashboard, and click on Add Subgraph
Enter the name Celo NFT Marketplace. Your generated subgraph URL should match the subgraph name we set in the CLI earlier, that follows GITHUB_USERNAME/celo-nft-marketplace. In my case, this looks like,
Fill in the rest of the information however you'd like
Click on Create Subgraph

Now we are good to go! Run the following command in your terminal:

yarn deploy

This should compile your subgraph into WASM, upload some files to IPFS, and deploy your subgraph! If you get some output that looks like this, you're good to go!

Build completed: QmPEnC2jtZhbArAuu6NuYTyfU7HpmcwbMv1dNg5CNWWnqc

Deployed to https://thegraph.com/explorer/subgraph/haardikk21/Celo-NFT-Marketplace

Subgraph endpoints:
Queries (HTTP):     https://api.thegraph.com/subgraphs/name/haardikk21/celo-nft-marketplace
Subscriptions (WS): wss://api.thegraph.com/subgraphs/name/haardikk21/celo-nft-marketplace

✨  Done in 16.71s.

Open your Graph Dashboard and you should see your newly deployed subgraph there!

Click on it, and you may need to wait a bit for it to finish syncing. The Graph's nodes are scanning every block from the startBlock to the latest block to find any events that match our data sources!

👨‍🔧 The Playground

On the subgraph page, you will see a Playground. The Playground is an online interface to run queries on the GraphQL API exposed by the subgraph, and look at the data.

It should, by default, have a sample query for us that looks like this:

{
  listingEntities(first: 5) {
    id
    nftAddress
    tokenId
    price
  }
}

If we click the purple run button, you will see you get some JSON output like this:

{
  "data": {
    "listingEntities": []
  }
}

Currently this makes sense, since we haven't done anything with our contract and no events have been emitted, so no entities have been created in the datastore.

As we progress and build out the frontend for the dApp in Part 3, we will be creating listings, and seeing our subgraph's datastore getting populated over time with listing entities!

We can then just fetch the listing entities on our frontend through the GraphQL API programmatically!

😐 Updating your subgraph

If you made a mistake at any step, or something doesn't look right, all you need to do to update your subgraph is make whatever code changes you need to make, and then run yarn deploy again.

This will redeploy your subgraph, and you can do this as many times as you want.

Note, however, every time you redeploy the subgraph, the node will start syncing over again from the startBlock. This is because it's possible you may have made changes on how you want data to be stored - for example, changing how you calculate the ID of each entity, or maybe adding/removing properties from the entity, etc.

Therefore, each update will require you to wait a little bit for the sync to complete, and wait for the node to catchup to the latest block.

Conclusion

To verify this level, submit your subgraph URL below and select The Graph as the network.

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

NFT-Marketplace-Part-2.md

NFT-Marketplace-Part-2.md

Ship a true NFT Marketplace on Celo - Part 2

Subgraph Development

🧶 Installing Yarn

👨‍🔬 Setting Up

😎 Git Good

🔑 Adding your Deploy Key

⛩ File Structure

🤨 The Manifest

🧱 The Schema

👀 The Script

🚢 Ship It

👨‍🔧 The Playground

😐 Updating your subgraph

Conclusion

Files

NFT-Marketplace-Part-2.md

Latest commit

History

NFT-Marketplace-Part-2.md

File metadata and controls

Ship a true NFT Marketplace on Celo - Part 2

Subgraph Development

🧶 Installing Yarn

👨‍🔬 Setting Up

😎 Git Good

🔑 Adding your Deploy Key

⛩ File Structure

🤨 The Manifest

🧱 The Schema

👀 The Script

🚢 Ship It

👨‍🔧 The Playground

😐 Updating your subgraph

Conclusion
